CSIP Level 1 Cabling: Test Cabling
Test Cabling Test cabling and cabling connections are illustrated in Figure 11-12 and Figure 11-13. Pinout
information for the test cable is listed in Table 11-5.
Figure 11-12 Acquisition Frontplane to Laptop Serial Port Cable Assembly (P/N 453561170191)
Connects to
Laptop Serial Port
Connects to
Acquisition
Frontplane
See Table 11-5
J1
PIN 4
PIN 1
PIN 6PIN 1
PIN 9
PIN 5
