CSIP Level 1 Troubleshooting: System Software Tools
errors. The port also reports the checksums for the Channel Board flash. The system should
remain off until the proper setup has occurred.
NOTE The FEC debug port can be used to determine if there is a Channel Board fault, but
does not determine which board is faulty. To determine the faulty board, log onto Tech
Admin and use system diagnostics.
➤ To use the FEC debug port to determine if the front end is faulty
1. Refer to Figure 11-13 and connect the system to the laptop.
2. On the laptop, click Start, Programs, Accessories, Communications, HyperTermi-
nal.
3. If the new connection dialog box appears, enter a name and click OK.
4. Configure the HyperTerminal settings as indicated in Tabl e 9- 6.
Table 9-6 FEC Debug Port HyperTerminal Settings
Parameter Setting
Connect To tab
Connect using COM1
COM1 Properties
Bits per second 19200
Data bits 8
Parity None
Stop bits 1
Flow control Xon/Xoff
