4535 611 98931 iE33 Service Manual Page 142
CSIP Level 1 Installation: Installation Procedures
Installation Procedures
Figure 5-3 Installation Procedure List
Video Monitor Articu-
lation Arm
Shipping Strap Brackets
Uncrating the iE33
Ultrasound System
Crating the iE33
Ultrasound System
Upper OEM Deck Shelf and
Strapping (Dual OEM)
Lower OEM Deck and
Strapping (Single OEM)
