CSIP Level 1 Installation: Installation Procedures
Upper OEM Deck Shelf and Strapping (Dual OEM)
Figure 5-48 Preparing Upper Shelf OEM Deck Strapping
Butterfly bracket
Strap
Velcro end of strap
Ring
1
➤ To install or remove the
upper-shelf OEM
1. Open the strapping kit and prepare
two straps in the configuration
shown.
Return to Installation Procedure List.
