Philips iE33 - Table 15-3 S5-1 Sector Array Transducer

4535 611 98931 iE33 Service Manual Page 464
CSIP Level 1 Transducers: Transducer Specfications
Table 15-3 S5-1 Sector Array Transducer
Parameter Specification
Part number 21314A
Intended application Adult cardiology
Imaging modes 2D, M-mode, Color M-mode, steerable PW Doppler, High PRF
Doppler, Color Doppler, Tissue Doppler Imaging, Harmonics,
and XRes image processing
Elements 80
Clinical options Adult Cardiology, Contrast Cardiology (LVO)
Frequency range 1.3-3.2 MHz
PW Doppler frequency 1.6-3.5 MHz
CW Doppler frequency 1.647-1.667 MHz
Penetration 14 cm (minimum)
Lateral resolution, -20 dB
at depth
5.3 mm max at 12 cm
Axial resolution, -20 dB
at depth
1.9 mm max at 12 cm
Biopsy guide capability None
S/W version released on Initial release
