4535 611 989314730-0047-01iE33 Service Manual Page 313
CSIP Level 1 Disassembly: Disassembly Procedures
Figure 10-53 Frontplane Warning Label
CAUTION Refer to Figure 10-53. This warning label is on the front of the
Frontplane assembly. Read all warnings before proceeding with
Frontplane disassembly.
WARNING
Remove all frontplane shield mounting screws before
lifting handle.
Ensure frontplane is seated before lowering handle.
Do not exceed 25lb (55 kg) pressure on handle.
Failure to do so may damage board connections and
card cage mechanism.
Return to .Disassembly Procedure List
(1 of 2)
To Next Page
