4535 611 989314730-0047-01iE33 Service Manual Page 184
CSIP Level 1 Installation: Installation Procedures
Figure 5-45 Attaching the Lower OEM Shelf to the Upper
OEM Shelf
Lower OEM shelf
Upper OEM shelf
Panhead screws (2 plcs)
14
14. Attach the lower OEM shelf to the
upper OEM shelf using two panhead
screws.
Return to Installation Procedure List.
