CSIP Level 1 Installation: Installation Procedures
Lower OEM Deck and Strapping (Single OEM)
Figure 5-38 Preparing Lower OEM Deck Strapping
Butterfly bracket
Strap
Velcro end of strap
Ring
Clip Clip
1
➤ To install or remove the lower
deck OEM
1. Open the strapping kit and prepare
two straps in the configuration
shown.
Return to Installation Procedure List.
