Philips iE33 - Table 9-2 Acquisition Card Cage Voltages

4535 611 98931 iE33 Service Manual Page 243
CSIP Level 1 Troubleshooting: Power Supply Information
Table 9-2 Acquisition Card Cage Voltages
Voltage
Voltage
Range (Vdc)
Monitored
By
+5.35 5.0 to 5.7 NAIM
-5.35 -5.0 to -5.7 NAIM
+3.65 3.4 to 3.9 NAIM
+15 14.0 to 16.1 NAIM
-15 -14.0 to -16.1 NAIM
+48 44.6 to 51.4 NAIM
+HV_IN 0 to 125 NAIM
-HV_IN 0 to -125 NAIM
+HV_OUT (pulser out) 0 to 120 NAIM
-HV_OUT (pulser out) 0 to -120 NAIM
+LV (pulser out) 0 to 12 NAIM
-LV (pulser out) 0 to -12 NAIM
TGC1, TGC2 -1.4 to 1.4 NAIM
HV Bias 0 to -HV_OUT NAIM
VX1 1.5 to 5 NAIM
VX2 1.5 to 5 NAIM
VX3+ 5 to 12 NAIM
VX3- -5 to -12 NAIM
Matrix TGC 0 to 12 NAIM
