Philips iE33 - Figure 5-1 Ethernet Connection Diagram

4535 611 98931 iE33 Service Manual Page 123
CSIP Level 1 Installation: Connectivity Information
Figure 5-1 Ethernet Connection Diagram
DICOM printer
(Stand-alone, No network)
Ethernet switch
To imaging network
(DICOM printers
DICOM servers)
AVIO Rear
Interface Panel
RJ45
jack
Network Interface Card:
• Auto-negotiating
• 10 or 100 Mbps
• Full or half duplex
DICOM server
(Stand-alone, No switch)
Or
Cross-over cable
