Philips iE33 - Figure 14-28 Speaker Box Assembly, Right

4535 611 98931 iE33 Service Manual Page 403
CSIP Level 1 Parts: Illustrations
Figure 14-28 Speaker Box Assembly, Right
1065-6358-01
1065-6359-01
1516-0074 (6 plcs)
1065-6389-01
1065-6663-01
Parent View
Right speaker box assembly
3500-3626-01
Disassembly
Speaker module assembly
3500-3731-01
Speaker (4 plcs)
System
