4535 611 98931 iE33 Service Manual Page 447
CSIP Level 1 Parts: Parts List
Figure 14-23 3500-3659-02 Enclosure, Side Cover, Rear, Right
Figure 14-24 3500-3548-02 Enclosure, Side Cover, Left
Figure 14-23 3500-3547-02 Enclosure, Side Cover, Right
Figure 14-23 1065-6180-02 Enclosure, Top, Control Panel Articulation
Figure 14-41 1065-6523-01 Extension, Brake Pedal, Left System brake assembly
Figure 14-41 1065-6522-01 Extension, Brake Pedal, Right System brake assembly
Figure 14-45
Figure 14-54
2100-1910-01 Fan, 12 V, 360 MA, 105 CFM, 119 mm, with
Connector
Two fans located on the filter tray and
one on each side of the AC tray
Figure 14-47 3500-3701-01 Fan Mounting Plate Assy, Platform Platform power supply
Figure 14-17 453561185151 Ferrite Sleeve, Cable, Snap-on, Broadband Used on USB printer hub cable
Figure 14-45 453561150251 Filter, Acquisition Card Cage
Figure 14-25 453561150191 Filter, Platform Card Cage Rear enclosure access door
Figure 14-45 3500-3700-01 Filter Tray/Fan Assy Acquisition Card Cage cooling fans
Figure 14-34 453561166571 Foot, Elastomeric, Splined TEE probe tray
Figure 14-1 3300-0355-01 Foot Switch, Triple
Figure 14-49 2700-0151 Fuse, 4 A, 250 V, Fast, 1/4x1-1/4, UL/CSA
Figure 14-28 1065-6389-01 Gasket, Foam Enclosure Seal Speaker boxes
Figure 14-38 1065-6708-01 Gasket, Retainer, Bottom Acquisition Card Cage
Figure 14-38 1065-6709-01 Gasket, Retainer, Top
Figure 14-16 3600-0246-01 Gasket, RFI, Finger, Clip, BE-CU, 2.5
Table 14-1 iE33 Ultrasound System Parts List (Continued)
Located On Part Number Part Description Notes/Reference
