4535 611 98931 iE33 Service Manual Page 448
CSIP Level 1 Parts: Parts List
Not shown 453561165761 Grease, Molygraph, SL3144, 3-oz Cartridge For brake pedal linkage, includes a
3-pack of 3-oz cartridges (for
application, see Figure 8-4)
Figure 14-8 3600-0047 Grommet, 0.375ID, 0.660D, 0.06PNL, RBR Monitor articulation
Figure 14-43
Figure 14-45
1065-6398-01 Grommet, Door, Removable Acquisition power supply and
filter tray
Figure 14-49 2700-0240-01 Holder, Fuse Part of battery assembly
Figure 14-15 2950-1155-01 Holder, Microphone, Rubber
Figure 14-26 3500-3738-01 Holder, Transducer, Assy, Left Located on system, left side column
Figure 14-26 3500-3737-01 Holder, Transducer, Assy, Right Located on system, right side column
Figure 14-19 453561166921 Holder, Transducer, Assy, Left Part of iE33 system control panel
Figure 14-19 453561166891 Holder, Transducer, Assy, Right Part of iE33 system control panel
Figure 14-17 453561185291 Hub, USB, 2.0, 2-Port, Bus Powered USB printer hub
Figure 14-50 3500-xxxx-xx HV Switcher Assy Includes mounting plate and hardware
Figure 14-10 1065-6652-01 Insert, Arm, Lower, Display Articulation Monitor articulation
Figure 14-26 3000-0879-01 Insert, Transducer Holder, Left
Figure 14-26 3000-0878-01 Insert, Transducer Holder, Right
Figure 14-37 1065-5752-02 Insulator, Frontplane
Figure 14-45
Figure 14-54
2950-1611-01 Isolator, Vibration, Fan Used on filter tray fans and AC tray fans
Figure 14-19 453561173851 Knob, Large, Push Rotate
Table 14-1 iE33 Ultrasound System Parts List (Continued)
Located On Part Number Part Description Notes/Reference
