4535 611 98931 iE33 Service Manual Page 393
CSIP Level 1 Parts: Illustrations
Figure 14-18 Control Panel
PARENT VIEW
Control panel assembly
453561175082
Keyboard
Control knobs and
transducer holder
See Figure 14-22
See Figure 14-19
Lower housing
See Figure 14-21
System
