4535 611 98931 iE33 Service Manual Page 444
CSIP Level 1 Parts: Parts List
Figure 14-41 1065-6553-01 Caster Link, Center, Brake Assy System brake assembly
Figure 14-41 1065-6552-01 Caster Link, Lever, Brake Assy
Figure 14-26 1065-6674-01 Catch, Transducer Holder
Figure 14-53 2700-0270-01 Circuit Breaker, 15 A, 250 V, with Line
Filter, UL
Figure 14-53 2950-1179-01 Clamp, CA, 3/8 D, 1/2W, 1/4 Screw, Ins, Al Used on AC Tray to retain power cord
Figure 14-6 1065-6566-01 Clamp, Cable, Single Used on the flat panel video monitor
Figure 14-32
Figure 14-33
1065-6205-01 Clip, OEM Strap
Used with strap
1065-2386-01,
only for
OEMs positioned on the lower OEM
deck shelf
Figure 14-18 453561175082 Control Panel Assy, Cardiovascular Includes Control Panel PCB and
Control Panel Connector PCB
Figure 14-9 1065-6430-02 Cover, Access, Cable, Display Articulation Monitor articulation
Figure 14-37 1065-5753-02 Cover, Acquisition Frontplane
Figure 14-8 1065-6445-01 Cover, Arm, Display Articulation Monitor articulation
Figure 14-27 1065-6556-01 Cover, Cable Access Tower, Left
Figure 14-27 1065-6557-01 Cover, Cable Access Tower, Right
Figure 14-48 1065-6242-01 Cover, Coffin, Rat Hole Cable access cover for cable between
Acquisition and Platform card cages
Figure 14-13 1065-6567-01 Cover, Disk Bay, Rear
Figure 14-50 1065-6227-01 Cover, HV Assy, Left
Table 14-1 iE33 Ultrasound System Parts List (Continued)
Located On Part Number Part Description Notes/Reference
