4535 611 98931 iE33 Service Manual Page 443
CSIP Level 1 Parts: Parts List
Figure 14-5 2950-0586-01 Bumper, 0.5-in x 0.14-in H, Clear Vinyl,
Adhesive Back
Video monitor
Figure 14-14 1065-6356-01 Button, Stand-by, Disk Bay Power On/Standby switch button, part
of front disk bay enclosure
3500-3628-01
Figure 14-32
Figure 14-33
3000-0877-01 Cable Cover Assy, OEM
Figure 11-15 Table 11-2 Cables, Power Distribution
Figure 11-14 Table 11-1 Cables, Signal Interconnect
Figure 14-38 2950-1594-01 Card Guide, 4.5-in Length, Snap-in, Deep,
Nylon
Acquisition Card Cage
Figure 14-38 2950-1570-01 Card Guide, 6-in Length, 0.062 PCB,
Snap-in
Figure 14-57 453561163761 Caster, 5-in, SH ABS, Swivel Lock, without
Brake
Rear caster (right rear caster is
connected to the swivel-lock pedal; left
rear caster is designed to free-swivel,
see Figure 10-82)
Figure 14-56 453561160311 Caster, 5-in, Swivel without Lock, with
Brake
Front caster (both front casters are
connected to the brake pedal)
Figure 14-41 3500-3684-01 Caster Linkage, Brake Assy System brake assembly, includes
1065-6552-01 (2 each) and
1065-6553-01
Table 14-1 iE33 Ultrasound System Parts List (Continued)
Located On Part Number Part Description Notes/Reference
