4535 611 98931 iE33 Service Manual Page 445
CSIP Level 1 Parts: Parts List
Figure 14-50 1065-6226-01 Cover, HV, Right
Figure 14-16 453561170151 Disk Drive, DVD/CD, Rewritable, ATAPI
INTFC
Figure 14-11 1065-6653-01 Elbow, Swivel, Articulation Display Monitor articulation
Figure 14-25 3000-0860-01 Enclosure, Access Door, Rear Rear main system card cage enclosure
Figure 14-4 3000-0858-01 Enclosure Assy, Front Video monitor
Figure 14-24 3500-3658-02 Enclosure, Cover, Filter Door
Figure 14-22 1065-6067-01 Enclosure, Cover, Keyboard QWERTY
Figure 14-25 3500-3703-01 Enclosure, Cover, Main, Rear
Figure 14-32
Figure 14-33
1065-6204-02 Enclosure, Cover, OEM Cable Used on systems with one and two
OEMs installed, see 3000-0877-01
Figure 14-24
Figure 14-31
1065-6377-01 Enclosure, Cover, OEM Cable Drop
Figure 14-24 3500-3675-02 Enclosure, Cover, OEM Deck
Figure 14-33 1065-6203-02 Enclosure, Cover, OEM Strap
Figure 14-23 3500-3657-02 Enclosure, Cover, Power Supply
Figure 14-21 453561166761 Enclosure, CP Housing, Bottom Left
Figure 14-21 453561166781 Enclosure, CP Housing, Bottom Right
Figure 14-23 3500-3628-01 Enclosure, Disk Bay, Column Front Assy Also encloses the Scanhead Select
connectors. Includes On/Standby switch
button, 1065-6356-01.
Table 14-1 iE33 Ultrasound System Parts List (Continued)
Located On Part Number Part Description Notes/Reference
