Philips iE33 - Figure 14-23 System Enclosures (Right Front View)

4535 611 98931 iE33 Service Manual Page 398
CSIP Level 1 Parts: Illustrations
Figure 14-23 System Enclosures (Right Front View)
PARENT VIEW
3500-3628-01
1065-6184-01
1065-6185-02
3500-3652-02
1065-6190-02
1065-6180-02
3500-3544-02
3500-3656-02
3500-3546-02
3500-3545-02
1065-6192-02
3500-3657-02
3500-3659-02
3500-3547-02
1065-6354-02
Transducer holder assy, right
See Figure 14-26
Transducer holder assy, left
See Figure 14-26
Disassembly
System
