4535 611 98931 iE33 Service Manual Page 456
CSIP Level 1 Parts: Parts List
Figure 14-38 453561157281 Shield, Strip, Clip-On, Perp, 16-in Length Acquisition Card Cage fingers
Figure 14-11 1065-6528-01 Sleeve, Elbow, Display Articulation Monitor articulation
Figure 14-9 453561161691 Sleeve, Mounting, Display Articulation
Figure 14-22 2950-1497-01 Slide Rail, Keyboard
Figure 14-27 3500-3627-01 Speaker Box Assy, Left Speaker box assemblies
Figure 14-27
Figure 14-28
3500-3626-01 Speaker Box Assy, Right
Figure 14-27
Figure 14-29
1065-6361-01 Speaker Box, Left
Figure 14-29 1065-6362-01 Speaker Box, Lid, Left
Figure 14-28 1065-6359-01 Speaker Box, Lid, Right
Figure 14-28 1065-6358-01 Speaker Box, Right
Figure 14-24 1065-6355-02 Speaker Grill, Left
Figure 14-23 1065-6354-02 Speaker Grill, Right
Figure 14-28 3500-3731-01 Speaker Module Assy
Figure 14-13
Figure 14-15
453561174311 Spreader, Disk Drive Assembly Metal housing for CD/DVD drive,
power On/Standby switch, and system
microphone
Figure 14-11 2950-1630-01 Spring, Disc, 5/16ROD, 0.49OD, 0.0075T, Ss Monitor articulation
Figure 14-8 2950-1636-01 Spring, Gas, 650N
Figure 14-14 1065-6391-01 Spring, Stand-by, Disk Bay
Table 14-1 iE33 Ultrasound System Parts List (Continued)
Located On Part Number Part Description Notes/Reference
