4535 611 98931 iE33 Service Manual Page 455
CSIP Level 1 Parts: Parts List
Figure 14-25
Figure 14-27
Figure 14-40
Figure 14-42
Figure 14-44
Figure 14-47
Figure 14-48
Figure 14-51
Figure 14-53
1518-0051 Screw, 10-32x1/2, Pnh, Sem, Pd, St, Zn
Figure 14-13
Figure 14-27
Figure 14-44
1530-0410-01 Screw, 10-32x.5, Flh, Pd, 82D, Nylok, S, Z
Figure 14-54 1530-0157-01 Screw, 10-32x5/8, Skh, Cap, Hd, Nylok, Zn
Figure 14-31 1518-0043 Screw, 10-32x3/4, Pnh, Sem, Pd, St, Zn
Figure 14-41 1065-6555-01 Screw, Brake Lever, Brake Assy System brake assembly
Figure 14-11 1065-6438-01 Screw, Jack, Display Articulation Monitor articulation
Figure 14-16 1630-0113-01 Screw, M3x6, Pnh, Pd, Int Sems, St, Bz
Figure 14-4 1630-0128-01 Screw, M4.5x16, Phd, Td, Tf, St, Zn Video monitor
Figure 14-53 1630-0025-01 Screw, M6x15, Din 42801, Hex, Spcl, Br, Ni AC tray ground stud
Figure 14-37 1065-5751-03 Shield, Acquisition Frontplane
Figure 14-9 1065-6707-01 Shield, Cable, Video, Display Articulation Monitor articulation
Figure 14-16 3500-3739-01 Shield, EMI, DVD
Table 14-1 iE33 Ultrasound System Parts List (Continued)
Located On Part Number Part Description Notes/Reference
