CSIP Level 1 Installation: Additional Image Adjustments
4. Experiment with the four settings listed below by sending four sets of images using each set-
ting and let the customer choose among them.
- DICOM GSDF Embedded (Gray scale DICOM Function.Default Setting)
NOTE DICOM GSDF is a standard method of exporting images that is dynamic. If you select
this method, the receiving PACs decides how to set the viewing parameters. (The
receiving device is in charge of settings.) In the following three choices, you are forcing
the exported images to be in a specific format that is not dynamic.
- DICOM Optimized for CRT
- DICOM Optimized for Legacy Compatibility
- Export Optimized for LCD
Loop Frame
Rate
As the loop frame rate increases, there is a corresponding increase in displayed image quality and
a decrease in the image transfer rate. The iE33 system allows the user to set the loop frame rate
to the acquisition rate, 30 Hz, or 15 Hz. This allows trade-offs in image quality and transfer
speed. Experimentation may be needed to determine the best customer setting.
NOTE For Xcelera 1.1, the 30 Hz setting is recommended
➤ To change the loop frame rate
1. Press Setups on the keyboard.
2. Click Print/Network.
3. Click the Printer/Capture tab. The Image Export dialog box is displayed.
4. Select the appropriate frame rate setting based upon customer expectations.
