4535 611 98931 iE33 Service Manual Page 113
CSIP Level 1 Installation: Peripheral Installations
Table 5-2 Mitsubishi HS-MD3000UA/EA VCR Control Settings
Parameter
NTSC Setting
(3000UA)
PAL Setting
(3000EA)
Front Panel Controls
Monitor MIX MIX
Audio HIFI HIFI
Keylock OFF OFF
Rear Panel Controls
75 Ohm Video ON ON
75 Ohm S-Video ON ON
Table 5-3 Mitsubishi HS-MD3000U/E and HS-MD3000UA/EA VCR
RS-232 Interface Adapter Switch Settings
Switch
NTSC Setting
(3000UA)
PAL Setting
(3000EA)
Cable Switch Straight (P) Straight (P)
DIP Switches 1-5 OFF OFF
DIP Switch 6 ON ON
DIP Switch 7 ON ON
DIP Switch 8 OFF OFF
