4535 611 989314730-0047-01iE33 Service Manual Page 306
CSIP Level 1 Disassembly: Disassembly Procedures
Figure 10-46 Speaker Mounting Plate Cable Connector
Speaker mounting plate
cable connector
11
11. Disconnect the speaker cable from
the speaker mounting plate cable
connector.
Return to .Disassembly Procedure List
(1 of 2)
