Philips iE33 - Table 15-7 L11-3 Linear Array Transducer

4535 611 98931 iE33 Service Manual Page 468
CSIP Level 1 Transducers: Transducer Specfications
Table 15-7 L11-3 Linear Array Transducer
Parameter Specification
Part number 21756A
Intended application Vascular
Imaging modes 2D, M-mode, Steerable PW Doppler, Color Doppler, Color
Power Angio imaging, Harmonics, SonoCT imaging, XRes image
processing and Panoramic Imaging
Elements 288
Clinical options Vascular, Carotid, Arterial, Venous, and IMA
Frequency range 3.7-9.6 MHz
PW Doppler frequency 3.6-4.0 MHz
Penetration 5.0 cm (minimum)
Lateral resolution, -20 dB at
depth
0.9 mm max at 2 cm
1.5 mm max at 4 cm
Axial resolution, -20 dB at
depth
0.7 mm max at 2 cm
0.8 mm max at 4 cm
Biopsy guide capability None
S/W version released on Initial release
