4535 611 98931 iE33 Service Manual Page 369
CSIP Level 1 Configuration: Primary PCB Locations
Figure 13-1 Acquisition Card Cage PCB Names and Locations
Call your Philips representative for
the part number and compatible
software version of system PCBs
Scanhead Select
Assembly
(SHSEL)
Front End Controller
(FEC)
Analog Input Module
(AIM)
Channel Board (CB3-CB0)
Frontplane
assembly removed
To Next Page
