4535 611 989314730-0047-01iE33 Service Manual Page 324
CSIP Level 1 Disassembly: Disassembly Procedures
Figure 10-64 Rear Panel Enclosure
Panhead screws (6 plcs)
1
➤ To remove or replace the sys-
tem power cord
1. Remove the six panhead screws
securing the rear panel enclosure
assembly. Set the assembly aside.
Return to . Disassembly Procedure List
(2 of 2)
