4535 611 98931 iE33 Service Manual Page 85
CSIP Level 1 Theory of Operation: Physical Structure
drives contains the operating system boot image and is used to boot the SIP application. Both
drives are involved in streaming-data operations and use the high-speed partition to provide
about 130 GB of high-bandwidth storage. Refer to Tab le 4 -1 for drive partition information.
• One hard drive for the Host Motherboard: Contains the ultrasound system operating sys-
tem, embedded operating system, system software, and transducer information.
Bluetooth Receiver
The Bluetooth receiver enables wireless remote control using RF technology to enable voice
control of the ultrasound system. The receiver may be used with or without a headset. Refer to
the operating instructions for more information.
Table 4-1 Host Hard Drive Partitioning
Drive Partition Function
C WIN XPE operating system
D Read/write thumbnails and associated data
E Read/write other data, including Quick Save presets, logs,
and so on
F Read/write installed Philips application software
