Philips iE33 - Figure 14-8 Video Monitor Articulation Arm (Upper)

4535 611 98931 iE33 Service Manual Page 383
CSIP Level 1 Parts: Illustrations
Figure 14-8 Video Monitor Articulation Arm (Upper)
Parent View
Elbow assembly
See Figure 14-11
453561171591
453561155151
453561155161
1065-6445-01
1065-6696-01
1065-6655-01
453561155131
453561150072
2950-1636-01
453561155171
1555-0036-01
3600-0047 (2 plcs)
453561152171
1065-6699-01
1565-0087-01
1565-0091-01
1555-0036-01
System
