4535 611 98931 iE33 Service Manual Page 452
CSIP Level 1 Parts: Parts List
Call your Philips
representative for
the part number
and compatible
software version
of system PCBs.
PCB Assy, Scanhead Select SHSEL
PCB Assy, SCI Adapter, PCI, 64B, 66 Mhz Dolphin D-340
Figure 14-8 453561155171 Pin, 0.1875, Diameter
Figure 14-8 453561171591 Pin, Hinge, Display Articulation Monitor articulation
Figure 14-8 1065-6696-01 Pin, Knurl
Figure 14-41 453561161401 Plate, Mount, Brake Assy System brake assembly
Figure 14-41 1065-6551-01 Plate, Plunger, Brake Assy
Figure 14-27 1065-6468-01 Platform, OEM Deck
Figure 14-36 1065-6155-02 Plenum, Top, Acquisition Card Cage
Figure 14-43 453561151171 Power Supply, Acquisition
Figure 14-43 3500-3699-01 Power Supply Assembly, Acquisition
Figure 14-47 1700-0134-01 Power Supply, Platform
Figure 14-52 3800-0082-01 Relay, Ss, 12 Vdc, 5 A at 100 to 240 Vac
Figure 14-9 453561168951 Retainer, Cable, Arm, Lower, Articulation
Display
Monitor articulation
Figure 14-10 1065-6574-01 Retainer, Insert, Display Articulation
Figure 14-11 1065-6529-01 Retainer, Jack Screw, Display Articulation
Table 14-1 iE33 Ultrasound System Parts List (Continued)
Located On Part Number Part Description Notes/Reference
