4535 611 98931 iE33 Service Manual Page 453
CSIP Level 1 Parts: Parts List
Figure 14-38 1065-6153-05 Retainer, PCB, Bottom, Left Acquisition Card Cage
Figure 14-38 1065-6272-04 Retainer, PCB, Bottom, Right
Figure 14-38 1065-6152-04 Retainer, PCB, Top, Left
Figure 14-38 1065-6271-04 Retainer, PCB, Top, Right
Figure 14-11 1065-6694-01 Ring Brg, Elbow, Swivel, Display Articulation Monitor articulation
Figure 14-9 1065-6693-01 Ring Brg, Lower Arm, Display Articulation
Figure 14-8 1065-6699-01 Ring Brg, Yoke, Display Articulation
Figure 14-11 1065-6440-01 Ring, Retainer, Elbow, Display Articulation
Figure 14-11 1065-6695-01 Ring, Slip, Elbow, Display Articulation
Figure 14-41 1065-6549-01 Rod, Pivot, Brake Assy System brake assembly
Figure 14-41 453561153071 Screw, 3/8-16, Shoulder 1.0L, Skh, Hd,
Nylok, S, Z
Figure 14-15
Figure 14-53
1514-0060 Screw, 4-40x3/8, Pnh, Sem, Pd, St, Zn
Figure 14-22
Figure 14-49
Figure 14-50
1516-0112 Screw, 6-32x1/4, Pnh, Sems, Pd, St, Zn
Figure 14-11 1530-0344-01 Screw, 6-32x3/8, Flh, Pd, 100D, St, Zn
Table 14-1 iE33 Ultrasound System Parts List (Continued)
Located On Part Number Part Description Notes/Reference
