4535 611 989314730-0047-01iE33 Service Manual Page 157
CSIP Level 1 Installation: Installation Procedures
Figure 5-18 Locking the Right-Rear Caster
Right system
brake pedal
Right-rear caster
(facing inward)
2. Lock the right-rear caster using the
right system brake pedal. Ensure that
the caster is facing inward.
Return to Installation Procedure List.
