Philips iE33 - Table 11-4 iE33 System Test Cables

4535 611 98931 iE33 Service Manual Page 350
CSIP Level 1 Cabling: Cable Lists
2275-0176 Cable Assy, BNC, M/M, 6-ft, RG 59B/U, 75Ohm Diagram: Figure 11-10
453561153452 Cable Assy, USB, AVIO - OEM Diagram: Figure 11-9,
Figure 11-10, Figure 11-11, and
Figure 11-14
Table 11-3 iE33 System OEM Signal Interconnect Cables (Continued)
Part Number Cable Description Notes/Reference
Table 11-4 iE33 System Test Cables
Part Number Cable Description Notes/Reference
453561170191 Cable Assy, Acquisition Frontplane to Laptop Serial Connector
