4535 611 98931 iE33 Service Manual Page 345
CSIP Level 1 Cabling: Cable Lists
Cable Lists
Table 11-1 iE33 System Signal Interconnect Cables
Part Number Cable Description Notes/Reference
453561171931 Cable Assy, Adapter USB 2.0 to IDE without DC Connector Diagram: Figure 11-14
Parts Info: Figure 14-13
453561182621 Cable Assy, AGP to AVIO Diagram: Figure 11-14
453561182671 Cable Assy, AVIO-CAD to AVIO-RIP Diagram: Figure 11-14
453561155362 Cable Assy, AVIO to System Monitor, 1st Segment Diagram: Figure 11-14
453561159872 Cable Assy, AVIO to Speaker Diagram: Figure 11-14
453561156632 Cable Assy, Beeper Diagram: Figure 11-14
Parts Info: Figure 14-20
453561153682 Cable Assy, CD/DVD Diagram: Figure 11-14
Parts Info: Figure 14-13
453561182501 Cable Assy, Control Panel Connector Board to LCD Display,
iE33 (Req 2 cables)
Diagram: Figure 11-14
Parts Info: Figure 14-20
453561182581 Cable Assy, CPM to Connector PCB1 and PCB2 Diagram: Figure 11-14
Parts Info: Figure 14-20
453561152752 Cable Assy, ECG Connector Diagram: Figure 11-14
453561153402 Cable Assy, Ethernet Filter Part of accessory kit
Diagram: Figure 11-14
453561182701 Cable Assy, FEC to DSC and AVIO to FEC Diagram: Figure 11-14
453561156202 Cable Assy, FireWire, Motherboard to Bulkhead Diagram: Figure 11-14
3300-0355-01 Foot Switch and Cable Assy
