4535 611 98931 iE33 Service Manual Page 346
CSIP Level 1 Cabling: Cable Lists
453561164201 Cable Assy, Flat Panel Video Power, 2nd Segment Diagram: Figure 11-14 and
Figure 11-15
Parts Info: Figure 14-6
453561153662 Cable Assy, Host Motherboard to Bulkhead User USB Diagram: Figure 11-14
453561182631 Cable Assy, Host to SIP FireWire Diagram: Figure 11-14
453561153732 Cable Assy, Host USB-A to USB Bulkhead Diagram: Figure 11-14
453561182481 Cable Assy, Internal Ethernet Diagram: Figure 11-14
453561182711 Cable Assy, IPL (Host Dolphin to SIP) Diagram: Figure 11-14
453561153503 Cable Assy, On/Standby Switch Diagram: Figure 11-14
NOTE There is no connector
key on LED connector
P2. If the light comes on
with the system pow-
ered on, then the cable is
correctly connected to
the LED.
453561182681 Cable Assy, On/Standby Switch Assy Diagram: Figure 11-14
Parts Info: Figure 14-14
453561182611 Cable Assy, ON/STBY, Host Diagram: Figure 11-14
453561182351 Cable Assy, QWERTY LED Diagram: Figure 11-14
Parts Info: Figure 14-20
Table 11-1 iE33 System Signal Interconnect Cables (Continued)
Part Number Cable Description Notes/Reference
