Philips iE33 - Figure 10-17 Rear Side Enclosures

4535 611 989314730-0047-01iE33 Service Manual Page 277
CSIP Level 1 Disassembly: Disassembly Procedures
Figure 10-17 Rear Side Enclosures
Panhead screws (4 plcs)
33
32
32. Remove the four panhead screws
securing the left rear side enclosure
assembly.
33. Repeat step 32 to remove the right
rear side enclosure assembly.
Return to .Disassembly Procedure List
(1 of 2)
