4535 611 989314730-0047-01iE33 Service Manual Page 286
CSIP Level 1 Disassembly: Disassembly Procedures
Figure 10-26 Brake Pedal Extension Covers
Panhead screws (6 plcs)
Left brake pedal extension cover
Right brake pedal extension cover
51
51. Remove the six panhead screws
securing the left and right brake
pedal extension covers.
Return to .Disassembly Procedure List
(1 of 2)
