4535 611 98931 iE33 Service Manual Page 117
CSIP Level 1 Installation: Peripheral Installations
Printers
You can associate more than one printer to each of three print controls. When performing the
printer setup, the Restore Defaults buttons restore the settings to the manufacturer’s printer
settings, not the Philips’ recommended settings. Each Restore Defaults button restores only
the settings on that particular tab. To reenter the Philips’ defaults, you must enter each setting by
hand.
➤ To set up a color or a black-and-white printer
1. Press the Setups key.
2. Click Print/Network.
3. Click the Device Selection tab and Printer.
4. To configure a printer, select the printer name (not the check box) and click Edit. A printer
properties dialog box is displayed.
5. Cycle through the dialog boxes, selecting parameter settings as desired. Refer to Tabl e 5-6
for the (Philips-recommended) Sony UPD-23MD color printer settings. There are no settings
for the Sony UP-D895 black-and-white printer.
6. Click OK to exit each dialog box.
7. To specify the print controls used to send images to the printer (and to disk), select the
check boxes to the left of the printer names. If you have two of the same type of printer
check boxes selected, both printers will print when the appropriate controls are activated.
NOTE A maximum of two DICOM printers, two local printers, and one report printer can be
set up for use with the system. Connect the DICOM printers to the Ethernet port,
color printer to the USB 2.0 connector on the back of the DVD drive, and all other
printers to the upper two USB connectors on the AVIO-RIP or the back of the DVD
drive.
