CSIP Level 1 Transducers: Transducer Specfications
Table 15-2 X3-1 Matrix Transducer
Parameter Specification
Part number 21715A
Intended application Adult cardiology
Imaging modes 2D, Color, Harmonics, and XRes image processing
Elements 2400
Clinical options Adult cardiology, Contrast Cardiology (LVO)
Frequency range 1.3-4.0 MHz
Penetration 9.7 cm (minimum)
Lateral resolution, -20 dB at
depth
4.5 mm max at 8 cm
Axial resolution, -20 dB at
depth
2.2 mm max at 8 cm
Biopsy guide capability None
S/W version released on Initial release
