4535 611 98931 iE33 Service Manual Page 466
CSIP Level 1 Transducers: Transducer Specfications
Table 15-5 S8-3 Sector Array Transducer
Parameter Specification
Part number 21750A
Intended application Adult cardiology
Imaging modes 2D, M-mode, Color M-mode, steerable PW Doppler, High PRF
Doppler, Color Doppler, Tissue Doppler Imaging, Harmonics, and
XRes image processing
Elements 96
Clinical options Adult Cardiology
Frequency range 2.6-7.2 MHz
PW Doppler frequency 3.5-6.0 MHz
CW Doppler frequency 3.32-3.33 MHz
Penetration 8.5 cm (minimum)
Lateral resolution, -20 dB at
depth
3.6 mm max at 8 cm
Axial resolution, -20 dB at
depth
1.2 mm max at 8 cm
Biopsy guide capability None
S/W version released on Initial release
