4535 611 989314730-0047-01iE33 Service Manual Page 328
CSIP Level 1 Disassembly: Disassembly Procedures
Figure 10-68 AC Tray Screws
Panhead screws (2 plcs)
2
3
2. Remove the power cord. (See “To
remove or replace the system power
cord” on page 324)
3. Remove the two panhead screws
securing the AC tray to the cart
frame.
Return to .Disassembly Procedure List
(2 of 2)
