4535 611 989314730-0047-01iE33 Service Manual Page 178
CSIP Level 1 Installation: Installation Procedures
Figure 5-39 Removing the OEM Tray
Panhead screws (4 plcs)
OEM tray
OEM deck
2
3
2. Remove the four screws securing the
OEM tray to the OEM deck and set
them aside.
3. Lift the OEM tray off the OEM deck
and set it aside.
Return to Installation Procedure List.
