Philips iE33 - iE33 System Enclosures

4535 611 989314730-0047-01iE33 Service Manual Page 263
CSIP Level 1 Disassembly: Disassembly Procedures
iE33 System Enclosures
Figure 10-3 Upper Front Panel Enclosure
Panhead screws (2 plcs)
1
2
NOTE Cover removal must be accom-
plished in a sequential order.
Refer to text below for
sequence.
➤ To remove or replace the iE33
system enclosures
1. Remove the two panhead screws
securing the upper front panel enclo-
sure.
2. Slide the upper front panel enclosure
upward and remove it.
Return to .Disassembly Procedure List
(1 of 2)
