Philips iE33 - Figure 14-16 DVD Drive Housing (DVD Drive Assembly)

4535 611 98931 iE33 Service Manual Page 391
CSIP Level 1 Parts: Illustrations
Figure 14-16 DVD Drive Housing (DVD Drive Assembly)
1065-6249-01
453561170151
1065-6248-01
Parent View
1065-6675-01
3500-3739-01
1516-0074 (4 plcs)
1630-0113-01 (8 plcs)
1560-0061 (8 plcs)
3600-0246-01 (3 plcs)
Disassembly
1560-0046 (4 plcs)
System
