4535 611 98931 iE33 Service Manual Page 458
CSIP Level 1 Parts: Parts List
Figure 14-41 1565-0090-01 Washer, Equalize Pressure, 0.28ID, 0.63OD,
0.19T, S
Figure 14-15 1560-0065 Washer, Flat, #4, 0.122ID, 0.280OD, 0.03T,
St, Zn
Figure 14-16 1560-0046 Washer, Flat, #6, 0.156ID, 0.375OD, 0.049T,
St, Zn
Figure 14-16 1560-0061 Washer, Flat, #6, 0.312OD, 0.032T, St, Zn
Figure 14-53
Figure 14-34
1560-0051 Washer, Flat, #10, 0.203ID, 0.500D, 0.04T,
St, Zn
Figure 14-25
Figure 14-21
1565-0088-01 Washer, Flat, #10, 0.406OD, 0.04Thk, St,
Zn
Figure 14-56
Figure 14-57
1560-0052 Washer, Flat, 1/4, 0.28ID, 0.50D, 0.065T, St,
Zn
Figure 14-9 1565-0092-01 Washer, Flat, 2.5ID, 3.2OD, 0.04Thk, St, Zn
Figure 14-8 1565-0091-01 Washer, Flat, 5/16, 0.875OD, 0.064Thk, St,
Zn
Monitor articulation
Figure 14-56
Figure 14-57
1561-0036 Washer, S/R Lock, 1/4, 0.489OD, 0.062T, St,
Zn
Figure 14-8 1565-0087-01 Washer, Thrust, 0.375ID, 0.75OD, 0.0625T,
Brz
Monitor articulation, not shown in
illustration
Table 14-1 iE33 Ultrasound System Parts List (Continued)
Located On Part Number Part Description Notes/Reference
