4535 611 989314730-0047-01iE33 Service Manual Page 264
CSIP Level 1 Disassembly: Disassembly Procedures
Figure 10-4 Lower Front Panel Enclosure
Panhead screws (2 plcs)
3
4
3. Remove the two panhead screws
securing the lower front panel enclo-
sure.
4. Slide the lower front panel enclosure
upward and remove it.
Return to .Disassembly Procedure List
(1 of 2)
