4535 611 98931 iE33 Service Manual Page 441
CSIP Level 1 Parts: Parts List
Parts List
Table 14-1 iE33 Ultrasound System Parts List
Located On Part Number Part Description Notes/Reference
Figure 14-37 3500-3365-01 Acquisition Frontplane Assy
Figure 14-52 3500-3391-01 AC Tray Assy 120 V/240 V
Figure 14-52 3500-3745-01 AC Tray Assy 100 V
Figure 14-9 453561155191 Arm, Lower, Display Articulation Monitor articulation
Figure 14-7 453561155471 Articulation Arm Assy, Flat Screen Display
Figure 14-25 1563-0179 Ball Stud, 5/8 Length, 6.32x.25 Stud Rear enclosure access door
Figure 14-8 453561152171 Ball Stud, Gas Spring, 10 mm Monitor articulation
Figure 14-8 453561155131 Bar, Lower, Display Articulation
Figure 14-8 453561150072 Bar, Upper, Display Articulation
Figure 14-13 453561151571 Base, Pivot, Display Articulation
Figure 14-49 1700-0138-01 Battery, 6 V, 8.0 AH, Sealed, Lead Acid See note on battery replacement on
page 65
Figure 14-49 3500-3744-01 Battery Tray Assy
Figure 14-14 2950-1619-01 Bezel, LED, 5 mm, 0.25 Panel Hole, 2PC
Figure 14-56
Figure 14-57
1519-0022 Bolt, 1/4 20x3/4, Hex, St/G5, Zn
Figure 14-25 1065-6589-01 Bracket, Access Door Rear enclosure door latch
Figure 14-25 3000-0864-01 Bracket, Access Door Latch
Figure 14-45 1065-6623-01 Bracket Assembly, Filter Tray, Aft
Figure 14-45 1065-6622-01 Bracket Assembly, Filter Tray, Forward
To Next Page
