4535 611 98931 iE33 Service Manual Page 442
CSIP Level 1 Parts: Parts List
Figure 14-48 1065-6239-01 Bracket, Catch, Acquisition, Rear
Figure 14-16 1065-6249-01 Bracket, Disk Drive, Left
Figure 14-16 1065-6248-01 Bracket, Disk Drive, Right
Figure 14-16 1065-6675-01 Bracket, EMI, DVD
Figure 14-36 1065-6546-01 Bracket, L, Grounding Acquisition Card Cage
Figure 14-4 1065-6513-01 Bracket, Mount, Monitor, Horiz, EIZ0567
Figure 14-4 1065-6511-01 Bracket, Mount, Monitor, Right, EIZ0567
Figure 14-6 1065-6516-01 Bracket, Mount, Vesa, Eizo, L500, Monitor
Figure 14-54 1065-6559-02 Bracket, Platform, Card Cage Fan Rear cooling fans
Figure 14-53 1065-6595-01 Bracket, Power Cord Provides retention for the power cord
to AC tray receptacle
Figure 5-36
Figure 14-54
453561160051 Bracket, Shipping Strap For shipping purposes only
Figure 14-28 1065-6663-01 Bracket, Speaker Mounting
Figure 14-41 453561157701 Bracket, Swivel, Brake Assy System brake assembly
Figure 14-34 453561170901 Bracket, TEE Tray TEE probe tray
Figure 14-8 453561155161 Bracket, Tilt, Monitor
Figure 14-40 3500-3743-01 Brake Assembly, Core Cart
Figure 14-41 1065-6649-01 Brake Assembly, Left Pedal System brake assembly
Figure 14-41 1065-6648-01 Brake Assembly, Right Pedal
Table 14-1 iE33 Ultrasound System Parts List (Continued)
Located On Part Number Part Description Notes/Reference
