4535 611 98931 iE33 Service Manual Page 449
CSIP Level 1 Parts: Parts List
Figure 14-19 453561160161 Knob, Light Pipe, TGC/LGC
Figure 14-10 1065-6435-01 Knob, Locking, Display Articulation Monitor articulation
Figure 14-19 1065-6463-01 Knob, Small, Rotate
Figure 14-19 1065-6461-01 Knob, Touch Screen, Rotate
Figure 14-8 1065-6655-01 Knuckle, Display Articulation Monitor articulation
Figure 14-63 4535611 Label, 3x1, Met Poly, Sil, Therm Xfr Serial number
Figure 14-61 453561157471 Label, High Voltage Safety Backlight Inverter 600 Vac
Figure 14-58 453561161311 Label, Lock/Unlock, Display Articulation
Arm, Left
Lock/Unlock symbols
Figure 14-58 453561161301 Label, Lock/Unlock, Display Articulation
Arm, Right
Figure 14-63 453561156511 Label, Main System Model number, CE
Figure 14-65 453561154171 Label, Panel, AVIO-RIP, PCB Connector designation symbols
Figure 14-62 453561161261 Label, Pedal, Brake Lock Brake lock symbol
Figure 14-62 453561161151 Label, Pedal, Swivel Lock Swivel lock symbol
Figure 14-63 453561156521 Label, Power Switch Power switch location label
Figure 14-64 453561160521 Label, Software License, Windows XP
Embedded
Figure 14-58 453561180051 Label, System Badge iE33, product name
Figure 14-63 453561161321 Label, USB Symbol
Figure 14-64 453561161791 Label, Warning, Monitor PCB controls not field adjustable
Table 14-1 iE33 Ultrasound System Parts List (Continued)
Located On Part Number Part Description Notes/Reference
