4535 611 98931 iE33 Service Manual Page 446
CSIP Level 1 Parts: Parts List
Figure 14-23 1065-6185-02 Enclosure, Disk Bay, Column Insert
Figure 14-24 1065-6186-02 Enclosure, Disk Bay, Column Rear
Figure 14-24 3500-3653-02 Enclosure, Disk Bay, Column Side, Left
Figure 14-23 3500-3652-02 Enclosure, Disk Bay, Column Side, Right
Figure 14-23 1065-6184-01 Enclosure, Disk Bay, Rear Display
Figure 14-23 3500-3546-02 Enclosure, Front Bumper, Left
Figure 14-23 3500-3545-02 Enclosure, Front Bumper, Right
Figure 14-23 3500-3656-02 Enclosure, Front Panel, Lower
Figure 14-23 3500-3544-02 Enclosure, Front Panel, Upper
Figure 14-25 1065-6188-01 Enclosure, Main Cover, Rear Rear main system card cage enclosure
Figure 14-23 1065-6192-02 Enclosure, Mud Plate
Figure 14-32
Figure 14-33
1065-6376-02 Enclosure, OEM Shelf, Lower
Figure 14-32
Figure 14-33
453561155221 Enclosure, OEM Shelf, Upper
Figure 14-5 1065-6510-01 Enclosure, Rear Video monitor
Figure 14-24 1065-6191-02 Enclosure, Transducer Holder Base, Left
Figure 14-23 1065-6190-02 Enclosure, Transducer Holder Base, Right
Figure 14-5 1065-6520-01 Enclosure, Shroud, Monitor, Lower
Figure 14-5 1065-6521-01 Enclosure, Shroud, Monitor, Upper
Figure 14-24 3500-3660-02 Enclosure, Side Cover, Rear, Left
Table 14-1 iE33 Ultrasound System Parts List (Continued)
Located On Part Number Part Description Notes/Reference
