4535 611 98931 iE33 Service Manual Page 348
CSIP Level 1 Cabling: Cable Lists
453561179301 Cable Assy, AVIO - iButton and Platform Power Supply Diagram: Figure 11-15
453561158551 Cable Assy, AVIO to Fans, Battery and Temp Diagram: Figure 11-15
453561179281 Cable Assy, Backlight Inverter, iE33 (Req 2 cables) Diagram: Figure 11-14
Parts Info: Figure 14-20
453561156612 Cable Assy, Backlight Pot Diagram: Figure 11-14
Figure 14-20
453561153673 Cable Assy, CD/DVD and Flat Panel Power Diagram: Figure 11-15
453561153712 Cable Assy, Control Panel Articulation, 1st Segment Diagram: Figure 11-15
453561179872 Cable Assy, Control Panel Articulation, 2nd Segment, iE33 Diagram: Figure 11-14, and
Figure 11-15
Parts Info: Figure 14-20
2275-0388-01 Cable Assy, Cord, 3x1SQMM, 15-ft L, Harm, CEE-22 and 7 System power cord, 230 V
Diagram: Figure 11-15
Parts Info: Figure 14-53
2265-0274-01 Cable Assy, Cord, 3x14 AWG, 4.5ML, Unshielded, UL/CSA System power cord, 100/120 V
Figure 11-15
Parts Info: Figure 14-53
453561182601 Cable Assy, Host Power Diagram: Figure 11-15
453561182571 Cable Assy, Internal AC Tray Secondary Diagram: Figure 11-15
Table 11-2 iE33 System Power Distribution Cables (Continued)
Part Number Cable Description Notes/Reference
